Adept Lynx Platform User's Guide, Rev D
Page 119 of 126
Chapter 8: Maintenance
8.7 Spare Parts List
Part
Number
Description
Bundles, Major Components
99060-000 Bundle, Adept Lynx Main bundle (Lynx, Dock. Station, Joystick, software)
59060-000 Adept Lynx Top assembly (just the Lynx)
13558-000 Joystick assembly
11700-000 System, Adept Lynx Core
Docking Station
12477-000 Docking Station (Dock)
13091-000 Fuse, 1 A, 3AG (¼ x 1¼), Internal Docking Station fuse
04563-000 Fuse, 10 A, Time-lag, 5 x 20 mm, External Docking Station fuses (x 2)
02212-000L Fuse Drawer, 5 x 20 mm, Docking Station power entry side
12416-000 Roller, Docking Station
12417-000 Contact, Paddle, Docking Station (x 2)
12872-000 Assembly, Frame, Docking Funnel
Covers, Latches
12804-100 Cover: bumper (lower front)
12804-200 Cover: front (upper front)
12804-350 Cover: Right panel + light disc
12804-450 Cover: Left panel + light disc
12804-600 Cover: Hatch (Access Panel to Maint. Ethernet, Joystick)
12855-000 Push Latch, 3 kg retaining force, Black (Access Panel latch)
12804-700 Cover: Rear
12804-800 Cover: Battery door
12168-000 Latch, locking, flush, ABS Battery latch (contains the key)
Operator Panel
12800-000 Assembly, HMI Panel
12410-000 Push Button, Green, Panel Mount, Round
12411-000 Push Button, Red, Panel Mount, Round
12412-000 Push Button, Yellow, Panel Mount, Round
12413-000 Switch, Keylock, 2 Keypull Positions, 90° (contains HMI key)
