adept technology Lynx Platform User Manual

Adept Lynx Platform User's Guide, Rev D
Page 49 of 126
Chapter 4: Payload Structures
0
7.06 (0.28)
23.02 (0.91)
42.07 (1.66)
61.12 (2.41)
77.06 (3.03)
84.14 (3.31)
89.51 (3.52)
5.39 (0.21)
0
1.52
(0.06)
11.97
(0.47)
6.35
(0.25)
78.98
(3.11)
151.61
(5.97)
159.48
(6.28)
169.93
(6.69)
161
(6.34)
70
(2.76)
4x Ø5
C
L
C
L
Punch Thru
3 mm (0.12)
Clearance Area
HMI Panel
Profile
(0.2) Thru
Units in mm (in.)
Figure 4-6. Operator Interface Cutout Dimensions
Many other options are available. Details and specifications of the connections available are
covered in Connectivity on page 51.
Option Connections
The platform provides connectors for a user-supplied payload bumper and additional sonar
units that can be placed on the payload structure.
