Adept Lynx Platform User's Guide, Rev D

Page 70 of 126

Chapter 5: Connectivity

Batt Comm.

Connector type Mini-Fit

3 x 2

Use Battery control

Pin No. Designation Notes

1 GND

Connections to the Adept-Supplied Battery

2 RS232_BATT_RXD

3 RS232_BATT_TXD

4 FBAT_ALWAYS

5 START_BUTTON

6 OFF_BUTTON
