Adixen ASM 142 D - Test after Installation

To Next Page

To Previous Page

530

Valves installation and maintenance

GB 00051

Edition 07

- June

Test

after installation

After the valve installation, we

recommend

to perform a helium leak

test

to check the

vacuum

tightness.

CAUTION

ake

care with seal permeability. Do not

expose

the

seals

helium for an extended time.
