A 800
ASM 142
T echnical characteristics
GB 00212
-
Edition 03
- June
08
Audio alarm: 90 dB frequency modulated and adjustable audio signal
Hard vacuum Audio signal set point Adjustable throughout the entire measuring range
Sniffing Audio set point
Adjustable throughout the entire measuring range
Start-up time (average, at 20 °C):
Without autocalibration
1 min 3 s ± 10 %
With autocalibration
2 min 15 s ± 10 %
Time to reach test mode
(Hard
vacuum test):
inlet
por t
blanked-off
connected to
1.6 liter
volume
connected to
12.5 liter
volume
Gross leak test mode 1.8 s 4 s 30 s
Normal test mode 2.3 s 8 s 1 min 03 s
Miscellaneous:
Power voltage low voltage :
high voltage
:
100
- 130 V ± 10%
200 - 240 V ± 1 0%
Power frequency
50/60 Hz single phase
Power consumption (maximum)
< 1 kW
Start-up temperature
10 to 45° C
Ambient operating temperature
0 to 45° C
Storage temperature -25° C to 70° C
Storage temperature (detector equipped with the graphic interface
control panel)
-20° C to 60° C
max. 48 h at -20° C
max. 168 h at 60° C
Humidity (detector equipped with the
graphic interface control panel)
Ta ≤ 40° C
Ta > 40° C
85 % relative humidity max.
Absolute humidity must be
lower than the humidy of
85 % relative humidity
at
40° C (43.4 g/m
3
in the air)
Noise level (at 1 meter; audio alarm not operational, stand by mode)
57 dBA
House protection level 20C IP
W eight
56 kg / 123 lb
Inlet DN 25
2 /2
