Adixen ASM 142 D - Page 56

A 801
ASM 142 D - ASM Graph D+
T echnical characteristics
inlet por t
blanked-off
connected to
1.6 liter
volume
connected to
12.5 liter
volume
Gross leak test mode 3.5 s
21
s 2 min 15 s
Normal test mode
5 s
24 s
2 min 37 s
inlet por t
blanked-off
connected to
1.6 liter
volume
connected to
12.5 liter
volume
Gross leak test mode
3.5 s
7 s
45 s
Normal test mode 5 s 11 s 1 min 11 s
GB 01478
-
Edition 03
- June
08
Time to reach test mode
(Hard
vacuum test)
(ASM
142 D):
Time to reach test mode
(Hard vacuum test)
(ASM 142 Graph +):
Miscellaneous:
Power voltage low voltage :
high voltage :
100 - 130 V ± 1 0%
200 - 240 V ± 1 0%
Power frequency
50/60 Hz simple phase
Power consumption (maximum)
< 500 W
Start-up temperature
10 to 35° C
Ambient operating temperature 0 to 35° C
Storage temperature
-25° C to 70° C
Storage temperature (detector equipped with the graphic interface
control panel)
-20° C to 60° C
max. 48 h at -20° C
max. 168 h at 60° C
Humidity (detector equipped with
the graphic interface control
panel)
Ta ≤ 40° C Ta > 40° C
85 % relative humidity max.
Absolute humidity must be
lower than the humidy of
85 % relative humidity
at
40° C (43.4 g/m
3
in the air)
Noise level (at 1 meter; audio alarm not operational, stand by mode) (ASM 142 D)
50 dBA
Noise level (at 1 meter; audio alarm not operational, stand by mode) (ASM Graph D+)
60 dBA
House protection level
20C IP
Weight (ASM 142 D)
42
kg/92 lb
Weight (ASM Graph D+)
71 kg/156 lb
Inlet
DN 25
2 /2
