Adixen ASM 142 D - Page 80

B 310
GB 01368 -
Edition
04 -
June
08
Controlling the detector with a PC
computer through the
RS 232 interface
Procedure 1 -
2x
Mode = autotest
(1x
NEXT
for
ASM 142
S
and ASM 102 S)
2 - The first line of LCD screen is:
F1 on
........ RS232 *****
...
...
...
5 stars
3 -
F4
the autotest is started and F1 flash on
Following different tests, the stars are replaced by numbers.
If the
autotest is accomplished, the first line LCD screen become:
........ RS232 12345
...
...
...
2 /2
