A 100
Introduction to the ASM 182/192 series
GB 00976 - Edition 04 - September 04
Compact model
Compact version for leak testing applications where space is limited.
Compactness has always been synonymous with limited performance
and poor lay out: Alcatel has challenge this belief.
Transportability: the ASM 182 T/TD+ products are self-contained units
which can be installed on a cart for easier manœuverability.
Using its rotaty vane pump 2021SD, Alcatel designed an unmatched
concept delivering high performance in a well laid out system.
Its well-proven concept for the roughing/backing oil-free pump
(frictionless compact multi-stage roots) has been designed to achieve
high roughing capacity (25 m
3
/h - 15 cfm) with minimum dimensions.
Comfortable workstation and several roughing configurations for
extended and adapted capability.
Console version ASM 182 T with extended pumping speed capability
(T2) or leak testing large chamber.
Console version ASM 182 TD+.
Console version ASM 192 T2D+ with a extended pumping speed
capability for leak testing large chambers.
ASM 182 T
ASM 182 TD+
THE VERSIONS ACCORDING THE DETECTOR TYPES
PUMPING COMPACT VERSION CONSOLE VERSION
1 Rotary vane pump RVP 2021
1 Hybrid pump TMP 5154
ASM 182 T ASM 192 T
2 Rotary vane pumps RVP 2021
1 Hybrid pump TMP 5154
ASM 192 T
with 40 m
3
/h
roughing option
1 Rotary vane pump RVP 2021
1 Turbomolecular pump ATP 100
1 Hybrid pump TMP 5154
ASM 192 T2
2 Rotary vane pumps RVP 2021
1 Turbomolecular pump ATP 100
1 Hybrid pump TMP 5154
ASM 192 T2
with 40 m
3
/h
roughing option
1 Dry pump Type ACP 28
1 Molecular drag pump MDP 5011
1 Hybrid pump TMP 5154
ASM 182 TD+ ASM 192 TD+
1 Dry pump Type ACP 28
1 Molecular drag pump MDP 5006 HDS
1 Turbomolecular pump ATP 100
1 Hybrid pump TMP 5154
ASM 192 T2D+
Console model
ASM 192 T/T2
ASM 192 TD+
ASM 192 T2D+
