GB 00216 - Edition 02 - September 04
3/5
Alcatel Vacuum Technology France - ATH 200 User’s Manual
B 320
Connecting the detector directly to a printer
or another device
1
Configuration ticket
ASM1002 CONFIGURATION TICKET
VERSION: L125v1.0 r00
DATE:Jan/01/2003 TIME:00:00:07
SET-POINTS MENUS
audio level: 3
digital voice level: 3
hard vacuum alarm: fixed
hard vacuum reject point: 1.0E-07
sniffing alarm: fixed
sniffing reject point: 1.0E-04
sniffer probe clogged reject: 1.0E-06
bargraph zoom on reject point: no
depollution function: off
pollution reject point: 1.0E-05
antipollution GL function: on
pollution reject point: 3.0E-04
memo. function active: no
memo. display timer: no
memo. timer value(min:s): 00:10
cycle end function: operator
roughing overlap timer: on
roughing timer value(min:s): 00:10
test timer value(min:s): 00:10
start.timer value(min:s): 00:05
background suppression
activation: operator
trigger: reject point
GL setpoint (mbar) 1.0E+02
Normal setpoint (mbar) 1.0E-01
SPECTRO MENUS
automatic calibration: off
calibration check: operator
every: 0050 cycles
every: 0010 hours
filament in use: 2
electronic zero: 110
acceleration voltage(V): 217
electronic current(mA): 0.0
sensitivity coefficient: 01.00
He calibrated leak
location: internal
value: 1.0E-07
unit: mbar.l/sec
year: 2003
loss per year(%): 2.00
temperature(C): 20
temp.coefficient(%/C): 3.00
MAINTENANCE MENUS
high vac.mnt.periodicity(hours): 12000
high vac. mnt.due in(hours): 12000
filament#1 running time(hours): 0
filament#2 running time(hours): 0
customed mnt.period.(cycles): 5.0E+05
customed mnt.due in(cycles): 5.0E+05
bicolore remote: yes
primary pump1 used: yes
primary pump2 used: no
OTHER MENUS
test mode selection: normal
inlet vent mode: chamber
inlet vent delay(sec): 0
inlet vent open timer us: no
inlet vent timer value(min/sec): 00:09
hard vacuum correction: off
hard vacuum cor.coefficient: 1.00E+00
sniffing correction: off
sniffing cor.coefficient: 1.00E+00
unit: mbar.l/sec
display language: english
user interface: #4
password value: 5555
TYPICAL VACUUM VALUES
Pu_gf:1.00000 Mu_gf :1.0E+06
Pu_n :1.00000 Mu_n :00001.0
Mu_rld:00015.0
DATE AND TIME VALUES
last stop: Jan/01/2003 00:00:00
last start: Jan/01/2003 00:00:02
last calib.ok: Jan/01/2003 00:00:00
detector counter (h:m:s): 00000:00:50
