Adixen ASM 192 T2D PLUS - Calibration Checking Ticket with Internal Leak; Test Ticket

4/5
B 320
Alcatel Vacuum Technology France - ATH 200 User’s Manual
Connecting the detector directly to a printer
or another device
GB 00216 - Edition 02 - September 04
GB 00216 - Edition 02 - September 04
5/5
Alcatel Vacuum Technology France - ATH 200 User’s Manual
B 320
Connecting the detector directly to a printer
or another device
5
Calibration checking ticket
with internal leak
CALIBRATION INFORMATIONS:
DATE|Jan/01/2003 TIME|01:19:23
current internal temperature(C)| 24
current coef.sens| 00.78
global rate| 1.10E-07
background rate| 5.22E-11
calibrated leak-rate| 1.10E-07
target value| 1.10E-07
percent allowance (+/-)| 15
RESULT(%)| -0
6
Test ticket
DATE:Jan/01/2003
HOUR CASE PRESSURE LEAKRATE
00:28:26 start 3.8E+01 3.4E-11
00:28:55 GL 1.2E-02 1.4E-09
00:29:40 NR 6.3E-05
9.1E-06
00:29:45 stop 5.8E-05
NR
DATE:Jan/01/2003
HOUR CASE PRESSURE LEAKRATE
01:02:31 start 6.5E+01 4.8E-11
01:02:32 GL 4.6E+01 4.8E-11
01:02:33 NR 5.9E-02
1.8E+00
01:02:36 stop 9.9E-05
NR
Leak value
9.1E-06
1.1E-05
Leak value
1.8E+00
1.3E-05
Test result if Memo
function active
FAIL
1.3E-05
FAIL
Memo function C 550
