GB 00965 - Edition 05 - February 05
1/2
Installation
ASM 182 TD+ - ASM 192 TD+ - ASM 192 T2D+
User’s Manual
Detailed contents
B
B 100 Safety instructions
- Generalities
- Pump labels
- Leak detector labels
- Alcatel contact in case of emergency
B 110 Unpacking - Storage - Transportation
- Unpacking
- Handling the leak detector with a hoist and slings
- Precautionary measures for the leak detector installation
- Storage
B 200 Neutral gas purge and inlet vent connection
- Products concerned
- Connection to the leak detector
- Use
- Gas characteristics
B 210 ASM 182 - Connecting the detector to the installation
B 211 ASM 192 - Connecting the detector to the installation
B 300 Controlling the detector with the I/O interface
- Purpose of the I/O interface
- Location of the I/O interface
- Prepare the connector wiring
- The controls (inputs)
- The signals (outputs)
- 24 V DC Power supply
B 310 Controlling the detector with a PC computer through the RS 232 interface
- Purpose of the PC computer interface
- Location of the RS 232 interface
- RS 232 interface instructions
- Commands available for your leak detector
Preliminary
remarks
Throughout this User’s Manual, you could find this type of message
“Summary of screen C 140”: it refers to a specific chapter of the
User’s Manual. Please read it for further information.
