Adixen ASM 192 T2D PLUS - Physical Dimensions

86 pages

Save Page as PDF

To Next Page

To Previous Page

GB 00962 - Edition 03 - September 04

1/1

A 900

Dimensions (mm/inch)

ASM 182 TD+

280

(11)

456 (18)

444 (17.5)

421 (16.6)

461 (18.1)

487 (19.2)

594 (23.4)

inlet port DN 40

Alcatel Vacuum Technology France - User's Manual ASM 182/192 TD+ - ASM 192 T2D+
