A 801
ASM 192 T2D+
Technical characteristics
GB 01365 - Edition 02 - Février 02
Start-up time (at 20 °C):
Without auto-calibration 3 min 30 s ± 10 %
With auto-calibration 5 min ± 10 %
Time to reach test mode (hard vacuum test):
Volume 46 l 200 l 1000 l
Configuration
Standard
2 ACP 28 Option
Standard
2 ACP 28
Standard
2 ACP 28 Option
Gross leak
43 s 23 s 2 mn 59 s 1 mn 32 s 6 mn 40 s 6 mn 21 s
Normal
1 mn 2 s 33 s 4 mn 25 s 2 mn 18 s 16 mn 9 mn 41 s
High sensitivity
1 mn 31 s 54 s 6 mn 30 s 3 mn 48 s
25 mn 35 s
16 mn 44 s
Residuel at 1.10
-8
1 mn 51 s 1 mn 16 s 8 mn 20 s 5 mn 42 s 31 mn 7 s 22 mn 7 s
Residuel at 2.10
-9
2 mn 1 mn 24 s 8 mn 56 s 6 mn 24 s 31 mn 1 s 24 mn 4 s
Miscellaneous:
Power voltage
low voltage:
high voltage:
100 - 130 V
±
10%
200 - 240 V ± 10%
Power frequency 50/60 Hz single phase
Power consumption*
1 ACP 28 Version 2 ACP 28 Version
maximum at roughing (delay 1 sec.): 1.5 kVA 2.3 kVA
stabilized at roughing (max.): 1 kVA 1.9 kVA
stabilized in test mode or in standby mode: 0.8 kVA 1.3 kVA
Start-up temperature 10 to 40° C
Ambient operating temperature 10 to 40° C
Storage temperature (standard detector) -25° C to 70° C
Noise level (at 1 meter; audio alarm not operational, stand by mode) 66 dBA
House protection level 20 IP
Inlet DN 50
Hygrometry max. (at 40°C) 95 %
Weight 1 ACP 28 version:
2 ACP 28 version:
157 kg
190 kg
Part to be tested weight max. 30 kg
*Average power consumption for a cycle on a 200 liters volume to obtain 1.10-8 mbar.l/s.
