Adixen ASM 192 T2D PLUS - ASM 192: Connecting the Detector to the Installation

GB 01367 - Edition 03 - September 04
1/1
B 211
ASM 192: connecting the detector
to the installation
N
2
B 320
Main power
switch
Inlet port DN 50 (ASM 192 T2)
(ASM 192 T2D+)
Inlet port DN 40 (ASM 192 TD+)
(ASM 192 T)
LDS Probe
(accessory)
A 700
Remote control
C 400
Exhaust
Air inlet
B 200
Fuse of the 3
back plugs
Main power
cord
External control
system
(I/O interface)
B 300
PC
B 310
Nitrogen purge
(TD+ only)
B 200
Controlling the detector with a PC
computer through the RS 232 interface:
Refer to the RS 232 User’s Manual
delivered with your detector.
Alcatel Vacuum Technology France - User's Manual ASM 182/192 TD+ - ASM 192 T2D+
