Adixen ASM 192 T2D PLUS - Dimensions (MM;Inch) ASM 192 Series

GB 01663 - Edition 02 - September 04
1/1
A 901
Dimensions (mm/inch)
ASM 192 series
594
(23.4)
170
(6.7)
498
(19.6)
869
(34.1)
734 (28.9)
692 (27.2)
519
(20.4)
215
(8.5)
387(15.2)
46 (1.8)
Inlet port
DN 50: ASM 192 T2/ASM 192 T2D+
DN 40: ASM 192 T/ASM 192 TD+
Alcatel Vacuum Technology France - User's Manual ASM 182/192 TD+ - ASM 192 T2D+
