2/2
A 800
ASM 182 / 192 TD+
Technical characteristics
GB 01244 - Edition 03 - September 04
Displays and setpoints adjustments:
Inlet port pressure display range 10
3
to 10
-3
mbar / 10
5
to 10
-1
Pa
Audio alarm: 90 dB modulated and adjustable audio signal
Hard vacuum Audio signal set point 1.10
-19
to 9.9.10
19
Sniffing Audio set point 1.10
-19
to 9.9.10
19
Start-up time (at 20 °C)
Without auto-calibration < 4 min ± 10 %
With auto-calibration < 5 min 30 s ± 10 %
Time to reach test mode
(Hard vacuum test):
inlet port
blanked-off
connected to
1.6 l volume
connected to
60 l volume
Gross leak test mode 2 s < 6 s < 1 min 20 s
High sensitivityl test mode 4 s < 20 s < 3 min 20 s
Miscellaneous:
Power frequency low voltage:
100 - 130 V
±
10%
high voltage: 200 - 240 V ± 10%
Power frequency 50/60 Hz single phase
Power consumption (maximum) 1,5 kVA
Start-up temperature 10 to 40° C
Ambient operating temperature 10 to 40° C
Storage temperature (standard detector)
-25° C to 70° C
Storage temperature (ASM 182 TD+ equiped -20° C to 60° C
with the graphic interface control panel) max. 48 h at -20° C
max. 168 h at 60° C
Humidity
(ASM 182 TD+ equiped with
the graphic interface control panel)
Ta ≤ 40° C Ta > 40° C
85 % relative humidity max. Absolute humidity must be
lower than the humidy of
85 % relative humidity at 40°
C (43,4 g/m
3
in the air)
Noise level (at 1 meter; audio alarm not operational, stand by mode) 65 dBA
House protection level 20 IP
Inlet DN 40
Hygrometry max. (at 40 °C) 95 %
Weight ASM 182 TD+ :
ASM 192 TD+ :
88 kg
195 kg
