User Manual of TV5600-B01 Series Dispensing Control System
90
1) Arc type: Arc size
2) Plane of the arc: Determine the arc interpolation axis
3) Arc radius
4) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
7
Arc
XYZ reaches the specified end point through a specified point by arc
interpolation.Other axes follow the movement to the specified position
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
8
Full circle
XYZ returns to the start point through two specified points in arc
interpolation.Other axes follow the movement to the specified position
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
9
End point of
arc
Specify the end point coordinates of the three-point arc interpolation
1) XYZABC coordinates: Coordinates of each axis
2) XYZABC enable: Whether each axis participates in motion
3) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
4) Use default speed: Select Yes to run at the speed set in the file
parameter, or else use the speed set in speed ratio * file parameter
5) Speed ratio (%): This value is meaningful when the default value is not
used as above
10
Clockwise
ellipse
XYZ moves to the specified position in clockwise ellipse arc interpolation. It is
necessary to give the long and short axis radiusof the ellipse, the coordinates
of the circle center and the coordinates of the end point, and other axes
follow the movement to the specified position
1) Plane of the ellipse: Ellipse interpolation axis
2) Circle center coordinate 1: The circle center coordinates of the 1st axis
of the plane where the ellipse is located
3) Circle center coordinate 2: The circle center coordinates of the 2nd axis
of the plane where the ellipse is located
4) Ellipse radius 1: Radius of the first axis of the ellipse plane
5) Ellipse radius 2: Radius of the second axis of the ellipse plane
6) Whether the instruction is executed: Whether this programming point
(processing instruction) is executed during processing
11
Inverse
ellipse
XYZ moves to the specified position in inverse ellipse arc interpolation. It is
necessary to give the long and short axis radiusof the ellipse, the coordinates
of the circle center and the coordinates of the end point, and other axes
follow the movement to the specified position
1) Plane of the ellipse: Ellipse interpolation axis
