User Manual of TV5600-B01 Series Dispensing Control System
12
Chapter 2
System Overview
TV5600-B01 series dispensing control system is composed of TV5600-B01 handheld box + offline
motion control card based on OMC system. The two are connected by Modbus serial
communication. TV5600-B01 completes the work of human-machine interface, offline motion
control card completes the motion control and IO port operations, and constitutes a set of split,
full three-dimensionaland high-precision dedicated motion control system.
※Note: HMI is optional, and if provided, only WEINVIEW touch screen and its interface project
files are provided to achieve the burning function.
Product model
Numb
er of
axes
Digit
al
inpu
t
Digital
outpu
t
Controller
Handheld
box
HMI
( optional)
DJ904V1-A01
3
24
6
MCD904
TV5600-B0
1
DJ904V2-A01
DJ904V3-A01
DJ904V4-A01
4
24
6
DJ8849V1-A01
3
34
18
ADT-8849
DJ8849V2-A01
DJ8849V3-A01
4
34
18
DJ1600V1-A01
5
36
24
AMC1600P
DJ1600V2-A01
DJ1600V3-A01
6
36
24
