User Manual of TV5600-B01 Series Dispensing Control System
115
Appendix VII: ADT8849 Wiring Instructions
1.ADT-8849 input ports
JA
Wire
No.
Name
Function
JB
Wire
No.
Name
Function
1
INCOM
1
Input common 1 (+24V
power supply)
1
INCOM
2
Input common 2 (+24V
power supply)
2
IN0
X home (or X servo Z phase)
2
IN17
B home (or X servo Z phase)
B
IN1
Y home (or Y servo Z phase)
3
IN18
C home (or Y servo Z phase)
4
IN2
Z home (or Z servo Z phase)
4
IN19
Bpositive limit
5
IN3
R home (or R servo Z phase)
5
IN20
Bnegative limit
6
IN4
Xpositive limit
6
IN21
Cpositive limit
7
IN5
Xnegative limit
7
IN22
Cnegative limit
8
IN6
Ypositive limit
8
IN23
Universal input
9
IN7
Ynegative limit
9
IN24
10
IN8
Zpositive limit
10
IN25
11
IN9
Znegative limit
11
IN26
12
IN10
Rpositive limit
12
IN27
13
IN11
Rnegative limit
13
IN28
14
IN12
External start, system
configuration required
14
IN29
15
IN13
External emergency stop,
allow configuration
15
IN30
