User Manual of TV5600-B01 Series Dispensing Control System
the Z axis, perpendicular to the main axis direction, that is, the lateral direction is the X axis, and
the tool away from the workpiece is the positive direction. The right-hand Descartes coordinate
system is as follows:
1.02 Dispenser coordinate system
After getting the dispenser, we will find the coordinates of each axis are displayed on the
interface of the handheld box. The structure of the coordinate system of the general
dispenser mechanism is shown as figure below.
Due to the combination of the modules and the combination style, the dispenser
mechanism also has the following structure:
