one cycle processing, and outputs at low level when it enters the next
processing.
7) Outputfrom standby position: This signal outputs at high level when the
motor is in the standby position, and outputs at low level when the position
is moved.
8) Motor enable: Motor motion enable control port
F1
9) Glue gun switch 1-16 output: Correspond to the opening and closing of the
1-8 glue gun
F2
10) Glue gun change 1-16 output: Correspond to the gun change signal of 1-8
glue gun
F4
11)
-negative number, the
gun forward/backward delay becomes valid. It limitscylinder gun
forward/backward action together with gun forward/backward in-position
signal, waits for gun forward/backward in-position signal, and the waiting
timeis not less than the set gun forward/backward delay time before
proceeding to the next step
12) Cylinder gun forward/backward output: This parameter needs to be
configured when the cylinder is used in cylinder mode, or else it is set to -1
13) Gun change delay: The time required for the cylinder to change the gun until
the gun is replaced
F3
14) Lock Z-axis output port: Output port locks Z-axis
15) Lock Z-axis output port effective level: Lock Z-axis level
16) Lock Z-axis time: Z-axis locking time
1. ->In handheld box system parameter interface -> Press [ Vendor parameter] -> select
