Section 5, User Interface Guide - UIG-525, STS-1 MUX PM Statistics
61186003L1-1D 5-65
STS-1 Far-End Daily Statistics
STS-1 far-end daily statistics are maintained for the current 24-hour period and the seven
previous days.
Select
FAR END DAILY from the STS-1 Statistics menus screen.
Figure 5-36 shows an example of the STS-1 Far-End Daily screen.
Figure 5-36. STS-1 Far-End Daily PM Statistics
Shelf: 1 Slot: 4A ADTRAN MX2820 System 04/15/04 17:44
Unacknowledged Alarms: None TID: HTVLALEXD16
STS-1 Statistics - Far End Daily
Current 04/14 04/13 04/12 04/11 04/10 04/09 04/08
CV-L 3 0 10 0 0 0 0 0
ES-L 1 0 2 0 0 0 0 0
SES-L 0 0 0 0 0 0 0 0
UAS-L 0 0 0 0 0 0 0 0
CV-P 3 0 21 0 0 0 0 0
ES-P 1 0 2 0 0 0 0 0
SES-P 0 0 0 0 0 0 0 0
UAS-P 0 0 0 0 0 0 0 0
'?' - System Help Screen
