MX2820 System Manual
7-94 61186003L1-1D
5. Provision the TFTP server.
a. From the Network Management menu, select TFTP SERVER and press ENTER.
Figure 7-20 shows the TFTP Server menu screen
Figure 7-20. TFTP Server Menu
b. Input the hostname or IP address for the server, and press ENTER.
c. Press ESC until the MX2820 Main Menu appears.
FOLLOW-UP PROCEDURES
Once this procedure is complete, return to the procedure which called out this DLP and
continue with the tasks indicated.
Shelf: 1 ADTRAN MX2820 System 04/26/04 13:53
Unacknowledged Alarms: TID: HTVLALEXD16
Current TFTP Server : 10.200.2.223
Enter hostname:
'?' - System Help Screen
To Next Page
