ADTRAN MX2820 - Provision MUX Module Loopback Timeout; Introduction; Prerequisite Procedures; Procedure

61186003L1-1D 7-155
DLP-739
Provision MUX Module Loopback
Timeout
INTRODUCTION
This procedure provides step-by-step instructions to provision the loopback timeout for the
Multiplexer (MUX) modules.
PREREQUISITE PROCEDURES
Obtain all necessary local instructions before provisioning the loopback timeout.
NOTE
In the case of 1:1 protection, provisioning the Active MUX module
automatically provisions the Standby MUX module.
PROCEDURE
1. If not already connected, connect the VT100 terminal or PC to the craft port. For details,
refer to
DLP-715.
2. Logon to the MX2820 system. For details, refer to DLP-716.
3. From the MX2820 Main Menu, select
ACCESS MODULES, and press ENTER. The MX2820
Access Module menu screen displays.
4. From the Access Module Menus screen, select the slot number for the MUX module that is
to be provisioned, and press
ENTER.
The Access Module Main Menu displays.
