ADTRAN MX2820 - Figure 7-57. Loopback Timeout Provisioning Menu; Follow-Up Procedures

Section 7, User Interface Guide - DLP-739, Provision MUX Module Loopback Timeout
61186003L1-1D 7-157
6. From the Provisioning menu, select LOOPBACK TIMEOUT, and press ENTER.
Figure 7-57 shows the Loopback Timeout Provisioning Menu.
Figure 7-57. Loopback Timeout Provisioning Menu
7. Input the value for the preferred loopback timeout, and press ENTER.
8. Press
ESC as required to return to the MX2820 Main Menu.
FOLLOW-UP PROCEDURES
Once this procedure is complete, return to the procedure which called out this DLP and
continue with the tasks indicated.
Shelf: 1 Slot: 1A ADTRAN MX2820 System 04/26/04 16:57
Unacknowledged Alarms: None TID: HTVLALEXD16
Provisioning
Loopback Timeout: 60 minutes
1 - Disabled
2 - 1 minute
3 - 5 minutes
4 - 10 minutes
5 - 15 minutes
6 - 30 minutes
7 - 45 minutes
8 - 60 minutes
Selection: '?' - System Help Screen
