Section 8, User Interface Guide - TAP-100, MX2820 Troubleshooting Guide
61186003L1-1D 8-7
2. From the System Alarms menu screen select either SHELF ALARM STATUS or ALARM LOGS, and
press
ENTER.
Figure 8-2 shows an example of the Shelf Alarm Status screen for an 19-inch shelf.
Figure 8-2. MX2820 Shelf Alarm Status Screen
Figure 8-3 shows an example of the Alarm Logs screen for an 19-inch shelf.
Figure 8-3. MX2820 Alarm Log Screen
Shelf: 1 ADTRAN MX2820 System 05/04/04 09:29
Unacknowledged Alarms: None TID: HTVLALEXD16
Shelf Alarm Status
M Master Log
S SCU......... [Major]
1 A - ............ [None] B - ............ [None]
2 A - ............ [None] B - ............ [None]
3 A - ............ [None] B - ............ [None]
4 A - MX2820 M13.. [Critical] B - MX2820 M13.. [None]
5 A - ............ [None] B - ............ [None]
6 A - ............ [None] B - ............ [None]
7 A - ............ [None] B - ............ [None]
Select Log (M-Master, S-SCU, 1..7):
Shelf: 1 ADTRAN MX2820 System 05/04/04 09:29
Unacknowledged Alarms: None TID: HTVLALEXD16
Alarm Log - Master Alarms Alarms 1 to 11 of 11 Page 1 of 1
Date Time Pos Type Port Level Description Status
10/10/00 00:00:03 SCU MX2820 SCU Chassis Major –48V Bus A Fail Active
10/10/00 00:00:03 SCU MX2820 SCU Module Info Card Removed Cleared
10/10/00 00:00:12 4A MX2820 M13 DS2 #1 Major OOF Active
10/10/00 00:00:12 4A MX2820 M13 DS2 #2 Major OOF Active
10/10/00 00:00:12 4A MX2820 M13 DS2 #3 Major OOF Active
10/10/00 00:00:13 4A MX2820 M13 DS2 #4 Major OOF Active
10/10/00 00:00:13 4A MX2820 M13 DS2 #5 Major OOF Active
10/10/00 00:00:14 4A MX2820 M13 DS2 #6 Major OOF Active
10/10/00 00:00:14 4A MX2820 M13 DS2 #7 Major OOF Active
10/10/00 00:00:15 4A MX2820 M13 DS3 Critical OOF Active
10/10/00 00:00:15 4A MX2820 M13 DS3 Critical LOS Active
---------------------------->>> END OF ALARM LOG <<<----------------------------
Inverse = Active * = Unacknowledged Chronology = Ascending
(N)ext (P)rev (F)irst (L)ast (C)lear (A)cknowledge (S)elect Log (R)eset Log
