IXL-001
Task Index List
Find the Required Task in the List Below: For details, refer to:
Installation
Shelf and SCU Installation NTP-001
Unpack and Inspect Shelf DLP-500
Mount Shelf, Heat Baffle, and Fan DLP-501
Remove and Re-install Metal Cover DLP-502
Connect Power and Ground DLP-503
Install SCU in MX2820 Shelf DLP-504
Install Modules in MX2820 Shelf DLP-505
Connect MX2820 Wire-Wrap Posts DLP-506
M13 MUX Installation NTP-002
Clock Module Installation NTP-003
STS-1 MUX Installation NTP-004
Connect Low-Speed Cabling DLP-706
Connect RJ-45 Cable DLP-708
Connect High-Speed Cabling DLP-709
Connect Fan Module Alarm DLP-711
Make RS-485 Bus Connections Between Shelves DLP-712
Connect Shelf to the X.25 Network DLP-714
Connect Terminal or PC to Craft Port DLP-715
Verifying Fan Module Alarm Connection to the SCU DLP-723
Verifying Alarm Relay Output Connections DLP-724
Verifying Intershelf Communication DLP-725
Verifying SCU Communication over an IP LAN DLP-727
