NetVanta 4300/4400 Series Option Modules
61200890E2-34T Copyright © 2019 ADTRAN, Inc. 39
NetVanta USB WWAN NIM (P/N 1702803F1)
The NetVanta USB WWAN NIM (shown in Figure 19) provides a USB interface for the NetVanta 4430
only. For specific connection and configuration instruct
ions, refer to the NetVanta USB WWAN NIM Quick
Start Guide or the USB WWAN NIM and the Cellular In
terface Configuration Guide available on
ADTRAN’s Support Forum (
https://supportforums.adtran.com). See Table A-12 on page 60 for the USB
WWAN connector pinouts.
WWAN
Figure 19. NetVanta USB WWAN NIM
Features and Specifications
USB Interface
• Supported Standards: USB 2.0
• Connector: USB Type A
Compliance
• EMC - see Electromagnetic
Compatibility (EMC) Table on page 6.
• EN 60950-1
• IEC 60950-1
• UL/CUL 60950-1
• AS/NZS 60950-1
• RoHS Compliant
Environmental
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 70°C
• Relative Humidity: Up to 95 percent,
noncondensing
Physical
• Dimensions: 2.75-inch W x 4.25-inch D
