Description
1 R1 Transmit data to the network–Ring 1
2 T1 Transmit data to the network–Tip 1
3-6 — Unused
7 T Receive data from the network–Tip
8 R Receive data from the network–Ring
Description
1 R1 Receive data from the network–Ring 1
2 T1 Receive data from the network–Tip 1
3 — Unused
4 R Transmit data toward the network–Ring
5 T Transmit data toward the network–Tip
6-8 — Unused
Description
1 R1 Receive data from the network–Ring 1
2 T1 Receive data from the network–Tip 1
3 — Unused
4 R Transmit data toward the network–Ring
5 T Transmit data toward the network–Tip
6-8 — Unused
NetVanta 4300/4400 Series
58 Copyright © 2019 ADTRAN, Inc. 61200890E2-34T
Network Interface Module Pinouts
Table A-5. WAN-DDS Connector Pinouts
Pin Name
Table A-6. WAN-T1 Connector Pinouts
Pin
Name
Table A-7. WAN-E1 Connector Pinouts
Pin
Name
