Unit Installation NetVanta 4300/4400 Series
52 Copyright © 2019 ADTRAN, Inc. 61200890E2-34T
Installing a SODIMM for Expandable Memory
The NetVanta 4430 ships with a 200-pin, 256 MB SODIMM (P/N 1200813E1) installed. It can be
upgraded to provide 512 MB using the 200-pin, 512 MB SODIMM (P/N 1200814E1). Follow these
instructions to
install a SODIMM module.
Remove power from the unit.
Remove the screws holding the base unit and the co
ver together, and, if necessary, the two
mounting brackets.
Using a 3/16-inch hex driver, remove the two jack scr
ews located on either side of the DB-9 port.
Carefully lift and remove the unit’s cover
to expose the circuit board.
Once you have discharged your static electricity, pick up
the SODIMM by its top or sides. Do not
touch the gold contacts at the bottom.
Gently insert the module into the mem
ory slot at a slight angle (approximately 30 degrees) as
shown in Figure 24 on page 54. Note that the socket and module are both keyed, which means
the module can be installed one way only.
To avoid damage, do not use excessive force. To seat the module into the socket, apply firm,
e
ven pressure to each end of the module (see the arrows in Figure 25 on page 54) until you feel
it slip down into the socket. If you are having pro
blems getting the module to seat properly, try
rocking the module up and down slightly, while continuing to apply pressure. When properly
seated, the contact fingers on the edge of the module will almost completely disappear inside the
socket.
With the module properly seated in the socket, rotate the module
downward, as indicated in
Figure 26 on page 54. Continue pressing downward until the clips at each e
nd of the socket lock
into position. With most sockets, you will hear a distin
ctive CLICK, indicating the module is
correctly locked into position.
Replace the unit cover, screws, and mounting brackets.
Restore power to the unit.
• SODIMMs are intended to be installed only by qualified service personnel.
• There are three types of SODIMM memory modules used by ADTRAN: 200-pin DDR1,
200-pin DDR2, and 144-pin DDR2. Although these modules look very similar, they are
not interchangeable. Prior to beginning the upgrade process, make sure you have
purchased the correct upgrade module for your ADTRAN product.
• Before touching electronic components, make sure you are properly grounded. By
wearing a wrist strap (or using some other type of static control device), you can prevent
static electricity stored on your body or clothing from damaging your installation.
Instructions for Installing a SODIMM
Step Action
1
2
3
4
5
6
7
8
9
10
