Status Screen
The Status screen (Figure 7) provides information regarding the status of the QDFR.
Figure 7. Status Screen
Auto In Service Screen
The Auto In Service Status screen (Figure 8) displays the status of the equipment and
individual channels. The parameters are set through the QDFC, and are not provisionable
from the QDFR.
Figure 8. Auto In Service Status Screen
Shelf: 1 Slot: 2 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Status Screen
______ ______
DSX-1 | QDFC | | QDFR | DS1
| | | |
Ports 1-4 | |--------------------------------------| | Ports 1-4
| | | |
|______| |______|
Net Cust
Test Port: CH 1,Mon Test Port: CH 1,Mon
Fiber
Rx Status Loopbacks Rx Status Rx Status Loopbacks
--------- --------- ----------- --------- ---------
CH 1: LOS NONE LOS CH 1: SF NONE
CH 2: LOS NONE CH 2: LOS NONE
CH 3: LOS NONE CH 3: LOS NONE
CH 4: LOS NONE CH 4: LOS NONE
Shelf: 1 Slot: 2 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Auto In Service Status Screen
Current Auto In Service = ENABLED
Port State
---- ----------
EQPT In-Service
CH 1 In-Service
CH 2 In-Service
CH 3 In-Service
CH 4 In-Service
--------------------------------------------------------------------------------
Auto In Service Parameters are controlled by the QDFC
