Quad Fiber Remote (QDFR) Unit Installation and Maintenance Practice
16 61181307L7-5E
Self-Tests Screen
Selecting Self-Tests performs tests of the QDFC and QDFR, with no additional user input. If
all functions pass, the “Self Test Complete” message appears (Figure 16).
Figure 16. Self-Test Complete
Performance History Menu
The Performance History menu (Figure 17) displays the performance of each individual end of
the circuit. A single channel can be viewed by selecting the option number for the channel of
choice.
Figure 17. Performance History Menu
Shelf: 1 Slot: 2 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
SELF TEST COMPLETE
QDFC : Passed
QDFR : Passed
Shelf: 1 Slot: 11 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Performance History
1. Channel 1
2. Channel 2
3. Channel 3
4. Channel 4
5. QDFC/QDFR Fiber
Selection:
