Menu Descriptions
61181307L7-5E 17
Performance History Channel # Menu
The Performance History Channel # menu (Figure 18) displays the performance of a specific
channel. From this screen, the network or customer receiver may be selected.
Figure 18. Performance History Channel # Menu
Performance History Fiber Menu
The Performance History Fiber menu (Figure 19) displays the performance of the QDFC and
QDFR.
Figure 19. Performance History Fiber Menu
Shelf: 1 Slot: 11 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Performance History
Channel 1
Select the Receiver of Interest
1. Network Receiver (from Network)
2. Customer Receiver (from Customer)
Selection:
Shelf: 1 Slot: 11 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Performance History - Fiber - 24 Hour Data
QDFC Data QDFR Data
ES-L SES-L UAS-L ES-L SES-L UAS-L
00000 00000 65535 00000 00000 00000
01/04 00000 00000 65535 01/04 00000 00000 00000
01/03 00000 00000 65535 01/03 00000 00000 00000
01/02 00000 00000 65535 01/02 00000 00000 00000
01/01 00000 00000 65535 01/01 00000 00000 00000
12/31 ----- ----- ----- 12/31 ----- ----- -----
12/30 ----- ----- ----- 12/30 ----- ----- -----
12/29 ----- ----- ----- 12/29 ----- ----- -----
1. Definitions 3. 15 Min Data
2. Reset Fiber Data
Selection:
