ADTRAN QDFR Unit - Figure 20. Channel Performance History Screen, from Network; Figure 21. Channel Performance History Screen, from Customer

Quad Fiber Remote (QDFR) Unit Installation and Maintenance Practice
18 61181307L7-5E
The Channel Performance History of the DSX-1 Rx from the network is shown in Figure 20.
Figure 20. Channel Performance History Screen, from Network
The Channel Performance History of the DSX-1 from the customer is illustrated in Figure 21.
Figure 21. Channel Performance History Screen, from Customer
Shelf: 1 Slot: 11 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Channel 1 Performance History - DSX-1 Rx from Network - 24 Hour Data
Line Data Path Data
ES-L SES-L LOSS-L CV-L ES-P SES-P UAS-P CV-P
65535 65535 65535 0000000 00000 00000 00000 0000000
01/04 65535 65535 65535 0000000 01/04 00000 00000 00000 0000000
01/03 65535 65535 65535 0000000 01/03 00000 00000 00000 0000000
01/02 65535 65535 65535 0000000 01/02 00000 00000 00000 0000000
01/01 65535 65535 65535 0000000 01/01 00000 00000 00000 0000000
12/31 ----- ----- ----- ------- 12/31 ----- ----- ----- -------
12/30 ----- ----- ----- ------- 12/30 ----- ----- ----- -------
12/29 ----- ----- ----- ------- 12/29 ----- ----- ----- -------
1. Definitions 4. 15 Min Data
2. Reset CH 1 Data 5. View Next Channel
3. Toggle Network/Customer Data Selection:
Shelf: 1 Slot: 11 Total Access System mm/dd/yy hh:mm
Unacknowledged Alarms:
Channel 1 Performance History - DS1 Rx from Customer - 24 Hour Data
Line Data Path Data
ES-L SES-L LOSS-L CV-L ES-P SES-P UAS-P CV-P
00000 00000 00000 0000000 00000 00000 00000 0000000
01/05 00000 00000 00000 0000000 01/05 00000 00000 00000 0000000
01/04 00000 00000 00000 0000000 01/04 00000 00000 00000 0000000
01/03 00000 00000 00000 0000000 01/03 00000 00000 00000 0000000
01/02 00000 00000 00000 0000000 01/02 00000 00000 00000 0000000
01/01 00000 00000 00000 0000000 01/01 00000 00000 00000 0000000
12/31 ----- ----- ----- ------- 12/31 ----- ----- ----- -------
12/30 ----- ----- ----- ------- 12/30 ----- ----- ----- -------
1. Definitions 4. 15 Min Data
2. Reset CH 1 Data 5. View Next Channel
3. Toggle Network/Customer Data Selection:
