The above function codes define the relationship between the analog input voltage
and
analog input setup value. When the analog input voltage exceeds the setup
maximum input or
minimum input range, the excess part will be calculated as maximum input or
minimum input.
When the analog input is current input, 1mA current equals to 0.5V voltage.
In difference applications, 100% of analog input corresponds to different nominal
values. Refer
to all the application parts for details.
Several setting examples are shown in the following figures:
