Advanced Control C220 Series - Page 37

Mechanical and Electrical Installation
C220/C420 Mechanical and Electrical Installation
36
Brake resistor
M
U
V
W
R
S
T
AC three-
phase 380V
power supply
DI1
DI2
DI3
DI4
DI5
COM
AI1
AI2
GND
485+
485-
485 Interface
AO1
GND
Y1
COM
CME
T/A
T/B
T/C
Relay
output
Multifunctional digital input terminal 1
+10V
0~10V/0~20mA
ON OFF
CN4
Matching
resistor
selection
Digital output
terminal
I
U
CN2
I
U
CN3
NPN
PNP
CN1
+24V
Default
FWD
Default
REV
(-)
(+) PB
Multifunctional digital input terminal 2
Multifunctional digital input terminal 3
Multifunctional digital input terminal 4
Multifunctional digital input terminal 5
Analog output
0~10V/0~20mA
Fig.3-4：ADV 0.40 C220-M～ADV 1.50 C220-M
3.2.4 Main Circuit Terminals and Wiring
!
Danger
1. Make sure that the wiring operation shall be carried out only when the power
supply switch
is in OFF position, or there may be risk of electric shock..
