2. Only the professional technicians who have received training can perform
wiring, or it may cause injuries to the equipment and human body.
3. It shall be grounded reliably, or there may be risk of electric shock or fire
accident.
Caution
!
1. Make sure that the input power supply and the rated value of the inverter shall
be consistent, or it may damage the inverter.
2. Make sure that the motor is compatible with the inverter, or the motor may be
damaged or inverter protection may be caused.
3. Do not connect the power supply to the U, V, W terminals, or it may damage
the inverter.
4. Do not connect the brake resistor to the DC bus terminals (+) and (-) directly, or
there may be fire accident.
3.2.4.1 Description of main circuit terminals of single-phase inverter:
Terminals Name Description
L、N
Single-phase power
input
terminal
Connect to the AC single-
phase 220V
power supply
(+)、(-)
Negative and
positive
terminals of DC
bus
Shared DC bus input point
(+)、PB
Connecting terminal
of
braking resistor
Connect to the braking resistor
U、V、W
Output terminal of
inverter
Connect to the three-phase motor
Grounding terminal Grounding terminal
