Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
93
setup
value
function description
maintains the current frequency output.
23 PLC status reset
PLC pauses during the execution process. When it
resumes running, it can effectively restore to the
initial status of simple PLC via this terminal.
24
Swing frequency
pause
The inverter output with central frequency. Swing
frequency pauses.
25
Timer trigger
input
Closing time depends on F7-39,See details F7-39～
F7-40
26 Brake command
This terminal is enabled, and the inverter directly
switches to the DC brake status.
27
External fault
normally closed
input
After the external fault signal is sent to the inverter,
the inverter reports fault and stops.
Table 1 MS Speed Function Description
K
4
K
3
K
2
K
1
Frequency
Setup
Corresponding Parameter
OFF OFF OFF OFF MS speed 0 FC-00
OFF OFF OFF ON MS speed 1 FC-01
OFF OFF ON OFF MS speed 2 FC-02
OFF OFF ON ON MS speed 3 FC-03
OFF ON OFF OFF MS speed 4 FC-04
