Advanced Control C220 Series - Page 95

Parameter Description
C220/C420G General Flux Vector Control Inverter User Manual
94
K
4
K
3
K
2
K
1
Frequency
Setup
Corresponding Parameter
OFF ON OFF ON MS speed 5 FC-05
OFF ON ON OFF MS speed 6 FC-06
OFF ON ON ON MS speed 7 FC-07
ON OFF OFF OFF MS speed 8 FC-08
ON OFF OFF ON MS speed 9 FC-09
ON OFF ON OFF MS speed 10 FC-10
ON OFF ON ON MS speed 11 FC-11
ON ON OFF OFF MS speed 12 FC-12
ON ON OFF ON MS speed 13 FC-13
ON ON ON OFF MS speed 14 FC-14
ON ON ON ON MS speed 15 FC-15
Table 2 MS Speed Function Description
Termina
l 2
Termin
al 1
Speed-up/speed-do
wn
time selection
Corresponding Parameter
OFF
OFF
Speed-up time 1
F0-23
、
F0-24
OFF
ON
Speed-up time 2
F7-03
、
F7-04
ON
OFF
Speed-up time 3
F7-05
、
F7-06
ON
ON
Speed-up time 4
F7-07
、
F7-08
