127 SEALER FRAME ASSEMBLY
5.13 NBO Wide Seal Frame Assembly
PN: TA-T10280-S18NB
ITEM NO.
QTY.
Part No
DESCRIPTION
1
1
TP-T1-00200S18
SEALER FRAME
2
1
TP-T1MB00010-W18
SEALER ROD TIE BAR
3
1
TP-T1MB00016-S18
SEAL CYLINDER MOUNTING BLOCK
4
1
TP- T1MB00005-W18
FRONT GRIPPER PLATE
5
2
TP-T1MB00033-W18-1
SEAL GUIDE ROD (5.25” Pass Through)
5
2
TP-T1MB00033-W18-2
SEAL GUIDE ROD (6.25” Pass Through)
5
2
TP-T1MB00033-W18-3
SEAL GUIDE ROD (7.25” Pass Through)
6
2
TP-T1MB00057
HEATER BAR YOKE
7
2
TP-T1MB00144-1
SHIELD MOUNTING ROD (5.25” PASS-THROUGH)
7
2
TP-T1MB00144-2
SHIELD MOUNTING ROD (6.25” PASS-THROUGH)
7
2
TP-T1MB00144-3
SHIELD MOUNTING ROD (7.25” PASS-THROUGH)
8
2
TP-T1MB00022
GUARD ROD MOUNTING BLOCK
9
1
TP-T1MB00164
PIVOT CLAMP
10
1
TA-T10005-W18
PRESSURE BAR SUB ASSEMBLY
11
1
TA-T10006-W18
HEATER BAR SUB-ASSEMBLY
12
1
TA-T10019
NO HANDLE LATCH ASSEMBLY
13
1
TA-T10019LH
LEFT HAND LATCH ASSEMBLY
14
1
TA-T10012-W18
GROOVED ROLLER MOUNT ASSY
15
1
TP-102109
HEAT TREATED WASHER
16
1
TA-T10009
TEFLON GUIDE SUB-ASSEMBLY
17
2
TP- T1MO00023-W18
DROP FRAME SPACER
18
1
TP-T1MB00063-W18
LATCH SHAFT
19
1
TA-T10017
BAG FINGER GROUNDING ASSY
20
1
TP-T1MB00107-S18
MAGNETIC SENSOR BLOCK
21
1
TP-403146
MAIN CYLINDER (5.25” PASS-THROUGH)
21
1
TP-403242
MAIN CYLINDER (6.25” PASS-THROUGH)
21
1
TP-403241
MAIN CYLINDER (7.25” PASS-THROUGH)
22
1
TA-T10020-S14
MANIFOLD ASSEMBLY
23
2
TP-403245
AIR CYLINDER
24
1
TP-T1MD00277NB-S18
SHORT INTERNAL GUARD
25
2
TP-T1MD00276NB-S18-4
GUARD BRACKET
26
1
TP- T1MD00276NB-S18-2
NBO INTERNAL GUARD
27
2
TP-401257
ELBOW, 1/4" TUBE x 1/8 NPT
28
2
TP-401277
ELBOW 1/4" TUBE x #10-32
