Advanced Poly-Packaging T-1000 - Chapter 7: Trouble Shooting

133
D. Grooved Roller Mounting Subassembly
PN: TA-T10012
ITEM
NO.
QTY
PART NO.
DESCRIPTION
1
1
TP-T1MB00013
ALUMINUM ROLLER SHAFT
2
2
TP-T1MB00004NB
ROLLER MOUNTING BLOCK
3
1
TP-T1MB00012
ROLLER
4
2
TP-107227
BUSHING, THRUST NYLON
5
2
TP-504107
BEARING, 0.500 BORE, 1.125 0D, 9/32 WIDE
6
1
TP-T1MB00155
FILM WEB TENSION ROLL
7
1
TP-T1MB00156
FILM WEB TENSION SHAFT
8
2
TP-T1MC00121
REAR ROLLER CLIP
9
2
TP-107163
¼ ID x 3/8 x 0.250 BUSHING
