ARK-3381 User Manual 16
Figure 2.12: VGA Connector
2.3.9 USB Connector
The ARK-3381 provides one USB interface connector, which gives com-
plete Plug & Play and hot swapping for up to 127 external devices. The
USB interface complies with USB UHCI, Rev. 2.0 compliant. The USB
interface can be disabled in the system BIOS setup.
The USB connector is used for connecting any device that conforms to
the USB interface. Many recent digital devices conform to this standard.
The USB interface supports Plug and Play, which enables you to connect
or disconnect a device whenever you want, without turning off the com-
puter.
Table 2.10: VGA connector pin assignment
Pin Signal name
1Red
2Green
3Blue
4NC
5GND
6GND
7GND
8GND
9NC
10 GND
11 NC
12 NC
13 H-SYNC
14 V-SYNC
15 NC
