31 Chapter 3
3 . 1 3 I n s ta l l i n g t h e 2 . 5 " H a r d D i s k D r i v e ( H D D )
You can attach one enhanced Integrated Device Electronics (IDE) hard
disk drive to the ARK-3381's internal controller which uses a PCI local-
bus interface. The advanced IDE controller supports faster data transfer
and allows the IDE hard drive to exceed 528 MB. The following are
instructions for installation:
1. Remove the power cord.
2. Unscrew the four screws from bottom cover of the ARK-3381.
3. Remove the bottom cover of the ARK-3381.
4. Connect the IDE flat cable to the connector to the hard disk.
5. Screw back the bottom cover with the four screws.
3.14 Connecting Power
Connect the ARK-3381 to a 12~24 VDC power source. The power source
can either be from a power adapter or an in-house power source.
