ARK-3381 User Manual 70
17. The Jumper Setting Location of MIO-253 Module I/O board
Figure 6.18:
JP10
JP14
JP15
JP17
JP16
JP13
JP9
JP8
JP4
JP3
JP2
JP6
JP5
JP7
