Chapter 2 Hardware Configuration
2.2.4.6 COM3 RS232/422/485 setting (J6)
* Please check J4/J8 for COM3 RS232/422/485 setting as well
2.2.4.7 COM4 RS232/422/485 setting (J7)
* Please check J3/J5 for COM4 RS232/422/485 setting as well
2.2.4.8 COM3 RS232/422/485 setting (J8)
* Please check J4/J6 for COM3 RS232/422/485 setting as well
2.2.4.9 Clear CMOS (J9)
J6 COM3 RS232/422/485 Setting
Part Number
1653003260
Footprint HD_3x2P_79
Description
Setting Function
(1-3)*(2-4) COM3 RS232 (Default)
(3-5)*(4-6) COM3 RS422/485
4
5
3
6
12
J7 COM4 RS232/422/485 Setting
Part Number
1653003260
Footprint HD_3x2P_79
Description
Setting Function
(1-2) COM4 RS232 (Default)
(3-4) COM4 RS485
(5-6) COM4 RS422
4
5
3
6
12
J8 COM3 RS232/422/485 Setting
Part Number
1653003260
Footprint HD_3x2P_79
Description
Setting Function
(1-2) COM3 RS232 (Default)
(3-4) COM3 RS485
(5-6) COM3 RS422
4
5
3
6
12
J9 Clear CMOS
Part Number
1653003101
