13 EKI-1361/EKI-1362 User Manual
Chapter 2 Getting Started
2.2 Hardware
In this section, we will give you an overview of EKI-1361/EKI-1362 hardware and
installation.
2.2.1 LED Indicators
There are LEDs display the power status, network status, and serial communication
status located on the front panel of EKI-1361/EKI-1362, each of them has its own
specific meaning as below table.
Table 2.1: EKI-1361/1362 series LED Indicators
LED Name LED Color LED Description
PWR1
Green Power 1 is on.
Off Power 1 is off, or power error condition exists.
PWR2
Green Power 2 is on.
Off Power 2 is off, or power error condition exists.
Status
Status
Blinking: System is ready.
Steady on: The device server has been located by utility’s location
function.
Off System is not working.
LAN
Green
Blinking: Ethernet port is transmitting or receiving data.
Steady on: Ethernet has the good link for 10Mbps or 100Mbps
operations.
Off Ethernet is not working.
WLAN
Orange Steady on: WLAN link is ready
Off WLAN is not working.
Signal
Strength
Off 0~25% WLAN signal strength.
Orange
(One)
25~50% WLAN signal strength.
Orange
(Two)
50~75% WLAN signal strength.
Orange
(Three)
75~100% WLAN signal strength.
Serial
Tx, Orange Serial port is transmitting data.
Rx, Green Serial port is receiving data.
Off No data is transmitted or received through the serial port.
