3 EKI-1361/EKI-1362 User Manual
Chapter 1 Overview
1.2 Features
 Supports standard Wireless 802.11 b/g/n
 Supports MIMO 2x2 technology
 Expandable up 4096 serial ports for one single host
 Provides 10/100/1000 Mbps auto-sensing Ethernet ports for easy diagnostic
 Supports any baud rate setting from 50 bps up to 921.6 Kbps
 Supports various operation modes: COM port redirection (Virtual COM port),
TCP server/client, UDP server/client, control mode and RFC-2217 mode
 Easy to diagnostic LED indicators
 Supports multi-access features: allows maximum 5 hosts to access one serial
port simultaneously
 Allows a maximum of 16 peers in TCP/UDP client mode
 Mounts on DIN rail, wall, or panel easily
 Surge protection for RS-422/485 line and power supply
 SNMP MIB-II for network management
1.3 Specifications
WLAN Interface
 Standard Conformance: 802.11b, 802.11g, and 802.11n
 Network Modes: Infrastructure, Ad-Hoc
 Transmit Power:
– 802.11b: +16 dBm (typical)
– 802.11g: +16 dBm @ 6~36 Mbps, +11 dBm @ 54Mbps
– 802.11n/HT20: +16 bBm @ MCS 0 ~ 3, +9 dBm @ MCS 7, +19dBm @ MCS
9, +11 dBm @ MCS 15
– 802.11n/HT40: +16 bBm @ MCS 0 ~ 3, +8 dBm @ MCS 7, +19dBm @ MCS
9, +11 dBm @ MCS 15
 Receive Sensditivity: -82 dBm (Max.)
 Data Rate:
– 802.11b: 1, 2, 5.5, and 11 Mbps
– 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
– 802.11n:
- 20 MHz Channel:
1Nss: 65 Mbps @ 800 GI, 72.2 Mbps @ 400 GI (Max.)
2Nss: 130 Mbps @ 800 GI, 144.4 Mbps @ 400 GI (Max.)
- 40 MHz Channel:
1Nss: 135 Mbps @ 800 GI, 150 Mbps @ 400 GI (Max.)
2Nss: 270 Mbps @ 800 GI, 300 Mbps @ 400 GI (Max.)
 Transmission Distance: Up to 100 meters (in open areas with bundled external
antenna)
 Wireless Security:
– WEP: 64-bit/128-bit data encryption
– WPA, WPA2, 802.11i: Enterprise mode and Pre-Share Key (PSK) mode
– Encryption: EAP-TLS, EAP-TTLS, EAP-PEAP
 Antenna Connector: Reverse SMA
