5 EKI-1361/EKI-1362 User Manual
Chapter 1 Overview
General
LED indicators:
System: Power, System Status
WLAN: Signal Strength, Link
LAN: Speed, Link/Active
Serial: Tx, Rx
Power
Power input: 12 ~ 48 VDC, redundant dual inputs
Power connector: Terminal block
Power Consumption:
EKI-1361: 8W
EKI-1362: 9W
Power Line Protection: 1 KV burst (EN61000-4-4), 0.5 KV surge (EN51000-4-5)
Environmental
Operation Temperature: -30 ~ 65°C (-22 ~ 149°F)
Storage Temperature: -40 ~ 80°C (-40 ~ 176°F)
Operating Humidity: 5 to 95% RH
Regulatory Approvals
ECM: CE, FCC Part 15 Subpart B (Class B)
1.4 Package Check List
1 x EKI-1361/1362 Serial Device Server
Panel/Wall mounting bracket
DIN-rail mounting kit
CD-ROM for utility and user manual
Optional Accessory:
OPT1-DB9-AE D-sub 9 (female) to terminal block connector (for EKI-1000
series RS-422/485 use)
