99 Appx. C

C.4 CompactFlash connector(CN28)

Table C.4: CompactFlash Connector (CN28)

Pin Signal Pin Signal

1 GND 26 #CD1

2D3 27D11

3D4 28D12

4D5 29D13

5D6 30D14

6D7 31D15

7#CE 32#CE2

8 A10 33 #VS14

9#OE 34#IORD

10 A9 35 #IOWR

11 A8 36 #WE

12 A7 37 #IRQ

13 VCC 38 VCC

14 A6 39 #CSEL

15 A5 40 #VS2

16 A4 41 RESET

17 A3 42 #WAIT

18 A2 43 #INPACK

19 A1 44 #REG

20 A0 45 BVD2

21 D0 46 BVD1

22 D1 47 D8

23 D2 48 D9

24 IOCS16 49 D10

25 #CD2 50 GND
