PCA-6773 User’s Manual 2
Chapter 1 General Information
1.1 Introduction
PCA-6773 is a new standard ISA bus Half-sized SBC. With an Onboard
Intel ULV Celeron 400/650 Fanless CPU or LV Pentium III800(optional)/
933MHz processor, along with a VIA VT8606/TwiserT + VT82C686B
system chipset. The PCA-6773 support SDRAM up to 512MB, with an
optional SODIMM then memory can support up to 1 GB.
Other on-board features include an EIDE, FDD, LPT, 4USBs, and 2 serial
ports(RS-232 and RS-232/422/485).Watchdog timer & IrDA suppport, as
well as a 10/100Mbps Ehernet is provided. The SSD solution supports
Type I/II CompactFlash cards.
This product uses a VIA TwisterT chip with Integrated Savage4 2D/3D/
Video Accelerator and supports 4X AGP VGA/LCD interface and up to
8/16/32 MB frame buffer using system memory. 9/12/18/24/36 bit TFT is
also supported. PCA-6773 supports AC97 audio with the addition of the
optional PCM-231A-00A1 audio module.
Its dimension is follow standard ISA slot PC, this make it can match with
all half-sized chasis and can operate in high vibration enviorment.
1.2 Features
• Intel ULV 400, 650/LV800(optional), 933 MHz CPU on-board
• On board PCI SVGA VGA/LCD display
• 4X AGP graphics for high performance applications
• Low power consumption, requires no CPU cooling
fan(ULV400,650)
• 10/100 Mbps Ethernet
• Supports boot from USB device
• Supports wake-on-LAN
• Supports Ring-up by Modem
• Supports LCD backlight turn-off function
• RS-485 Auto-flow
